Resolution: 4CH AHD (Analog high defintion)

Record mode: Full record / Parking record

Jpeg capture: 720p / 960H / D1 jpg

*Playback

4CH 720p @15fps

4CH 720p @30fps

2CH 720p @20fps + 2CH 960 @30fps

*Search mode: time index / time direct / Event

*Networking Streaming

*Ethernet: RD45 giga x1 (static / DHCP)

*Optional: 3G/ 4G / Wifi

*Video input: BNC x 4 for AHD or SD

*Video output: RCA x 1 / VGA x1 (800x600)

*Audio input x 2 / output x 1

*TPMS: Support (TTL / RS232)

*RS485: Yes (PTZ)

*RS232: Yes (TPMS)

*Support: RTSP / Alarm speech / TPMS(TTL/RS232) / Car speeding pulse in / Car Voltage Detect

*PTZ Pelco - P / D

*Boot delay: 0 ~ 10 sec

*Power Control Camera Power bypass control

*Power in: DC9 ~ 36V

*Power output: DC 12V

*Operation Temperature: -30°C - +80°C

*Software:

PC playback viewer/ VMS remote server-viewer / Smart phone APP iOS-Android
