Size: 22.3 cm wide by 29.6 cm high by 21.7 cm deep

Power: 12 to 24 VDC or 12 to 24 VAC 50-60 Hz, 7 watts

Weight: 6 lbs (2.7 kg) – 7 lbs (3.2 kg) with optional backup battery

Wiring: 2 twisted-pair, shielded, AWG 22 or larger (such as Belden 82732)

Temperature: -10°C to +60°C – non-operating/storage (14°F to 140°F)

5°C to 40°C – operating (40°F to 110°F)

Relative Humidity

Non-Condensing:

5% to 95% – non-operating/storage (non-condensing)

20% to 80% – operating

Verification Time: 1 second or less

Memory Retention: 3 years using a standard internal lithium battery

Transaction Buffer: HP-3000 – 5,120 transactions

HP-4000 – 7,680 transactions

ID Number Length: 1 to 10 digits

Baud Rate: 300 to 28.8 K bps

Communications: RS-232, RS-422, optional Modem, optional Ethernet

User Capacity: HP-3000 – 512 users expandable to 32,512

HP-4000 – 530 users expandable to 3,498

Message Capacity: HP-4000 – 550 expandable to 3520 (not available with the HP-3000)

Function Keys HP-3000 – 2 user definable, HP-4000 – 10 user definable

Card Reader Input: Proximity, Wiegand, Magnetic Stripe, Bar Code

(5 VDC provided by HandPunch unit)

Door Controls: Lock output, Request to Exit input, Door Switch input

(open collector, 5 VDC present, sinks to ground, 100 mA max)

Alarm Monitoring: Tamper, Door Forced

Event Monitoring: There are a variety of monitoring options including events such as:

Invalid ID, Time Zone Violation, ID Refused, Try Again,

Power Failure

Time Zones: 62 total: 2 fixed, 60 programmable

Time Schedules: HP-4000 – 3 definable time schedules per user

Auxiliary Inputs 2 (open collector, 5 VDC present, sinks to ground, 100 mA max)

Auxiliary Outputs up to 3 user definable

(open collector, 5 VDC present, sinks to ground, 100 mA max)

Table 1: Specifications
