Size: 22.3 cm wide by 29.6 cm high by 21.7 cm deep

Power: 12 to 24 VDC or 12 to 24 VAC 50-60 Hz, 7 watts

Weight: 6 lbs (2.7 kg)

Wiring: 2 twisted-pair, shielded, AWG 22 or larger (such as Belden 82732)

Temperature: -10C to +60C – non-operating/storage (14F to 140F)

0C to 45C – operating (32F to 113F)

Relative Humidity

Non-Condensing:

5% to 85% – non-operating/storage

20% to 80% – operating

Verification Time: 1 second or less

Memory Retention: 5 years using a standard internal lithium battery

Transaction Buffer: 5187 transactions

ID Number Length: 1 to 10 digits

Baud Rate: 300 to 28.8 K bps

Communications: RS-232, RS-485 4-wire (RS-422),

RS-485 2-wire, optional Ethernet, optional Modem

User Capacity: 512 users expandable to 32,512

Card Reader Input: Proximity, Wiegand, Magnetic Stripe, Bar Code

Card Reader Output: Wiegand, Magnetic Stripe, Bar Code

Duress Code: 1 leading digit, user definable

Door Controls: Lock output (open collector, sinks to ground, 100 mA max),

Request to Exit input, Door Switch input

Alarm Monitoring: Tamper, Door Forced, Duress

Event Monitoring: There is a variety of monitoring options including events such as:

Invalid ID, Time Zone Violation, ID Refused, Try Again,

Power Failure

Time Zones: 62 total – 2 fixed, 60 programmable

Auxiliary Outputs 3 user definable (open collector, sinks to ground, 100 mA max)
