S6 Software Configurable Processor: H.264 D1 120 fps encode capability

Programmable Accelerator

Optimized for video, wireless, and encryption applications

Peripherals

One quad 10-bit Data Port supporting multiple modes includ?ing:

．SD Video (BT 656)—interleaved or progressive

．HD Video (BT 1120)—interleaved or progressive

．Video—4:4:4, 4:2:2, or 4:2:0

．Flow-controlled FIFO mode—8/10 bit or 16/20 bit

One PCIe port—supporting x1 and x4 (S6100 only)

One 16/32-bit DDR2 333–667 SDRAM port

One 10/100/1000 Ethernet MAC port

One Enhanced Generic Interface Bus (eGIB)

Two programmable serial ports

Two-wire Interface (TWI)

Serial Peripheral Interface (SPI)

Two I2S audio ports

Two UART ports with IrDA

General Purpose I/O (GPIO) and Interrupts

One standard test port supporting JTAG IEEE 1149.1

HSBGA – 27mm x 27mm
