RF Power 30-50Watt(adjustable)

Voltage DC28V

Current 3.7A

Modulation COFDM 2K QPSK

RF Bandwidth 4/8MMHz(adjustable)

FEC 1/2 2/3 3/4 7/8

Guard Interval 1/32 1/16 1/8 1/4

Encryption AES 128/256 Bits

Max speed 600km/h

Video Input:

BNC: D1 standard definition

HDMI: HD1080I/1080P, 720P, 576, 480

SDI:HD1080I/1080P, 720P, 576, 480

Video compression format H.264

RF Interface N

Work environment -40℃~70℃

Case Material Aluminum

Size 220*275*78mm

Weight 7.6kg
