Power supply DC7.5-12V/ 0.9A-13A

Frequency 300-900MHz(optional)

Bandwidth 2/2.5/4/8M(adjustable)

Power Output 1Watt

AV Interface CVBS, HDMI, SDI

Encryption AES 128 bits

Constellation QPSK,16QAM

FEC 1/2,2/3,3/4,5/6, 7/8

Guard Interval 1/32,1/16,1/8,1/4

Carrier 2K

Video Compression

H.264

Resolution

Standard 720P, 1080P

RF Interface SMA

Video Format PAL/NTSC（self-adaption）

Size 100*59*22mm

Weight 195g(without battery)
