RF Power 15-25 Watt(customizable)

Voltage DC11-14.5V

Current 1.9A

Modulation COFDM 2K QPSK

Constellation QPSK,16QAM,64QAM

RF Bandwidth 4/8 MHz(adjustable)

FEC 1/2 2/3 3/4 7/8

Guard Interval 1/32 1/16 1/8 1/4

Encryption AES 128/256 Bits

Max speed 600km/h

Video Input

BNC: D1 standard definition

HDMI: HD1080I/1080P, 720P, 576, 480

SDI:HD1080I/1080P, 720P, 576, 480

Video compression H.264

RF Interface N

Size 220*275*78mm

Weight 4.5kg
