Frequency 300-2500MHz available

Bandwidth 5M/10M/20M/40MHz (Adjustable)

RF power 30dBm (33dBm/36dBm Optional)

Sensitivity -102dBm maximal

Modulation DSSS/CCK BPSK/QPSK OFDM BPSK/QPSK//16-QAM/64-QAM

Working voltage 12V

Power consumption 5W

RF interface SMA * 2

Ethernet port Standard RJ-45 * 2

Operation Web Software

Dimension 131*103*29mm

Weight 450g

Distance P2P

1~1.5km LOS on ground level

500m NLOS on ground level

15~20km LOS from UAV to ground station
