Working frequency 1430-1444MHz(Automatic frequency selection)

Modulation FHSS

RF bandwidth 5M/10M

RF power 0.5W (1W-2W can be customized)

Channel support 4 channel standard definition sync

Sensitivity -93dBm

Data serial port TTL/RS232

Ethernet Standard RJ45

Protocol E802.11

Baud rate 115200bps maximum

Dimension 87*78*26mm

Weight 193g

Working voltage DC 5V

Working current 0.5A

Power consumption <2.5W

1000m LOS (Ground to command center)

8-20km LOS (on UAV)

2-10km LOS (Marine area)
